Product | Single Channel Potentiostat/Galvanostat/EIS
WPG Series
WPG100e
  • Standard model
  • Voltage range : ±10V (standard)
  • Current range : ±1A (8 ranges, standard)
  • Customer's specified range is available.
  •

      응용 분야

    Application

    • Battery / Micro fuel cell
    • Membrane
    • Corrosion
    • Sensor
    • Photo Electrochemistry
    • Electrosynthesis / Electrolysis
    • User defined EChem application



    Features

    • Standard model
    • Affordable price
    • 16 bit ADC, DAC
    • Voltage range : ±10V (standard)
    • Current range : ±1A, 100mA, 10mA, 1mA, 100uA, 10uA, 1uA, 100nA
      (8 ranges, standard)
    • Compliance voltage range : ±12V (standard
    • Data sampling time : >500usec
    • Power : 30Watt
    • Suitable for low & high current range experiments
    • Accurate control & measurement
    • Battery cycle test is available
    • Importing/exporting data file
    • TCP/IP communication
    • User's specification available upon request
    • Compatible with IVMANTM DC data analysis software without purchasing license code
    • Free software upgrade



    Experimental Techniques

    Electroanalytical techniques.

    • Cyclic voltammetry
    • Linear sweep voltammetry
    • Chrono-amperometry
    • Chrono-coulometry
    • Chrono-potentiometry


    Corrosion measurement

    • Tafel plot
    • Potentiodynamic
    • Potentiostatic
    • Galvanostatic
    • Cyclic polarization
    • Ecorr vs. time
    • Linear polarization resistance



    Energy Test

    • CC/CV (Lithium battery) test menu
    • CC/CC (NiCd(NiMH) battery) test menu
    • Steady state CV
    • Pstat IV curve
    • Gstat IV curve
    • EVS (Electrochemical voltage spectroscopy) test
    • PITT (Potentiostatic intermittent titration technique) test
    • GITT (Galvanostatic intermittent titration technique) test



    Options

    • Temperature measurement
    • Auxiliary voltage measurement
